Commonly known as galvanized strip pipe, it is welded by direct bending and forming of galvanized steel strip, and the cross section is square or round.
1) Grade: Q195, Q215, Q235, Q345, A500
2) Thickness: 0.5-20mm
3) Size: 10x10-500x500mm
Product specificaion
Product Name | Pre galvanized rectangular square hollow tube |
Material | Q195, Q215, Q235, Q345 |
Zinc coating | 30g-300g/m2 |
Standard | DIN GB |
Shape | Square shape, rectangular shape, round shape |
Payment | T/T, L/C |
Delivery | Within 7 days |
Zinc coating | Pre galvanized zinc coating 30g/m2 or customized(30g/m2 - 100g/m2); |
Size details
SQUARE HOLLOW SECTION | RECTANGULAR HOLLOW SECTION | WALL THICKNESS |
20*20 25*25 30*30 | 20*40 30*40 | 1.7-2.75 |
40*40 50*50 | 30*50 25*50 30*60 40*60 | 1.2-4.75 |
60*60 | 50*70 40*80 40*50 | 1.2-5.75 |
70*70 | 60*80 50*80 100*40 | 1.5-5.75 |
80*80 75*75 90*90 | 60*100 50*100 120*60 100*80 | 1.5-8.0 |
100*100 | 120*80 | 1.7-8.0 |
120*120 | 160*80 150*100 140*80 | 2.5-10.0 |
140*140 150*150 | 100*180 200*100 | 2.5-10.0 |
160*160 180*180 | 200*150 | 3.5-12.0 |
200*200 | 250*150 | 3.5-12.0 |
250*250 280*280 | 250*200 300*200 | 4.5-15.75 |
300*300 | 350*200 350*250 400*200 | 4.5-15.75 |
350*350 | 350*300 450*250 400*300 500*200 | 4.5-15.75 |
400*400 500*500 | 450*300 450*200 400*350 400*250 500*250 500*300 400*600 | 4.5-20.0 |
Packing details
1. OD 350mm and below In hexagonal seaworthy bundles packed by steel strips, With two nylon slings for each bundles
2. above OD 350mm in bulk or according to custom opinion
3. 25 tons/container and 5 tons/size for a trial order;
4. For 20" container the max length is 5.8m;
5. For 40" container the max length is 11.8m.
