Spiral steel pipe

Spiral steel pipe is made by steel coil, extrusion forming under the normal temperature, then taken the technology of double wire and double-faced submerged-arc welded.
Spiral steel pipe, also known as spiral or helix spiral steel pipe, is a low-carbon steel or low-alloy structural steel strip at a certain helix angle (called molding angle) rolled into a tube, and the tube is made of welded joints It can be produced with a narrow strip of large diameter pipe.
During molding process of spiral welded steel pipe, steel plate has uniform deformation and light residual stress, thus the surface has no scratches. Spiral steel pipe has more flexible thicknesses and diameters, especially in making high-grade thick pipes with small or medium aperture, these techniques has incomparable advantages in satisfying your needs.

Commodity	API 5L Gr.B ssaw spiral welded steel pipe
Outer Diameter	219-3000mm
Wall Thickness	5-30mm
Length	3-17M according to client requirement
Standard	API 5L, EN10255, EN10219, EN10210, EN39, BS1387, ASTM A53, ASTM A500, ASTM A36, ISO 65，JIS G3444,DIN 3444, ANSI C80.1, AS 1074, GB/T 3091
Material	Gr.A, Gr.B, Gr.C, S235, S275, S355, A36, SS400, Q195, Q235, Q345
Surface	Hot dipped galvanized with zinc 220~260g/m2; Painted with black/varnish lacquer; Oil on the surface to prevent rust; Bare pipe without painting: Epoxy painting/FBE coating/3PE coating
Pipe End	Plain end/ Bevel end; Threaded on two ends, one end with coupling, one end with plastic cap
Packing	OD not less than 273mm: Loose packing,piece by piece. OD less than 273mm: In hexagonal seaworthy bundles packed by steel strips. small sizes nested into big sizes.
Applications	Petrol, gas, water pipe, construction, shipbuilding, fluid pipe
Trade Term	FOB, CFR, CIF, EXW, FCA
Delivery Time	15-45 days (based on quantity)
Payment Term	T/T, LC
